TABLE OF CONTENTS
Model Identification Numbering System
Axle Identification
Components
Parts List
Bearing Preload Spacers
End Yoke Assemblies
Housings
Kits
Spacer Kit
Differential Case with Bolts
Ring Gear and Pinion
Bearing Preload Spacer
Bearing and Seal
Bearing and Cup
Service Carriers
Note – Carriers Designed w/ 127591 Seal
1
2
3
4
5
5
5
5‐6
7
8
GENUINE SPICER SERVICE PARTS
Should an axle assembly require replacement component parts, it is recommended that
Spicer Heavy Axle Service Parts be used. Spicer Heavy Axle Service Parts are manufactured
under the same rigid specification as are original equipment axle components. This assures
the customer who uses genuine Spicer service parts, maximum reliability for a Spicer Heavy
Axle assembly. They may be obtained through your vehicle manufacturer. The use of non‐
original Spicer service parts may cause premature component failure and may void the
warranty.
The items included in this book are currently being offered as service parts at the time of
printing. The part numbers and illustrations are provided specifically for reference purposes
only. Therefore, Spicer reserves the right to update this manual without notice or liability.
MODEL IDENTIFICATION NUMBERING SYSTEM
S
Family
(Spicer)
Nominal Load
Carrying Capacity
(135 = 13,500 Lbs.)
(150 = 15,500 Lbs.)
Gearing Type
(S = Single Reduction)
Differential Option
(N = No-SPIN
®
Differential)
1
