Spicer Drive Axles Illustrated Parts List S135-S, S150-S User Manual
Page 10

8
NOTE – CARRIERS DESIGNED W/ 127591 SEALS
In October 2000, Dana release S150PB carriers for Navistar that incorporated new design pinion seal and yokes.
The parts listed below are those items unique to these designs. The carrier’s designs can be recognized by the
carrier part numbers. All 360CA107 and 360CA108 carriers are designed this way.
Bearing Kit w/127591 seal…………………………….360KS104‐X
Pinion Seal …………………………………………………..127591
Carrier Sub Assembly – Parking Brake Opt…..360CS102‐X
Pinion Yokes…………………………………………………contact Dana Driveshaft Division
360KS104-X BOM
Part Number
Description
Quantity
360HA100
Bearing Cup – Inner Pinion
1
HA102
Bearing Cup – Differential
2
HB105
Bearing Cone – 3984
2
360HB100
Bearing Cone – Inner Pinion
1
HB104
Bearing Cone – Outer Pinion
1
012495
Bearing Cup – Outer Pinion
1
127591
Pinion Seal
1
