Spicer WING STYLE COMPONENTS User Manual
Page 8
Universal Joint 3 Lips Sealing with plug
3050101000
LM
3L
HWD
Slip Joint without U-Joint
3644930010
YS
370
135
M18x1,5
25
°
Tube Yoke (Centering dia. for U-Joints fully machined)
3645350001
M18x1,5
25
°
Tube Yoke (Centering dia. for U-Joints Undersized)
3645383000
M18x1,5
25
°
Tube (Length 1 meter)
3832190133
219x13,3
Bolt
3814930001
HWD 110-42 useful
M18x1,5
Kit sliding shaft without tube (fix joint and slip joint)
3600001112
RL
3L
HWD
YS
130
M18x1,5
25
°
219x13,3
Short couple without U-joint
3697967000
YS
475
135
M18x1,5
25
°
310M230 - 14,5C
Universal Joint 3 Lips Sealing
3050232000
R
3L
HWD
Universal Joint 3 Lips Sealing with plug
3050421000
LM
3L
HWD
Slip Joint without U-Joint
3644930011
YS
370
135
M22x1.5
219x13.3
Tube Yoke (Centering dia. for U-Joints fully machined)
3636270008
100
M22x1.5
25
°
219x13.3
Tube Yoke (Centering dia. for U-Joints Undersized)
3636270011
101.2
M22x1.5
25
°
219x13.3
Tube (Length 1 meter)
3832190133
219x13.3
Bolt
3815220004
HWD 105-50 useful
M22x1.5
Kit sliding shaft without tube (fix joint and slip joint)
3600001113
RL
3L
HWD
YS
135
M22x1.5
25
°
219x13,3
Short couple without U-joint
3698021000
YS
464
135
M22x1.5
25
°
260M150 - 15C
Universal Joint 2 Lips Sealing
3050523001
R
2L
HWD
Universal Joint 2 Lips Sealing with Plug
3050A69000
SF
2L
HWD
Slip Joint without U-Joint
3612740030
YS
337.5
135
M20
25
°
160x10
Tube Yoke (Centering dia. for U-Joints fully machined)
3645363003
94.6
3/4" 16 UNF
25
°
160x10
Tube Yoke (Centering for U-Joints Undersized)
3645385001
94.6
3/4" 16 UNF
25
°
160x10
Tube Yoke (Centering dia. for U-Joints fully machined)
3645363001
94.6
M20
25
°
160x10
Tube Yoke (Centering for U-Joints Undersized)
3645385000
94.6
M20
25
°
160x10
Tube (Length 1 meter)
3831600010
160x10
Bolt
3815030007
12 Point Head HWD 88,9-63,5 useful
3/4" 16 UNF
Bolt
3815030006
12 Point Head HWD 90-52 useful
M20
Short couple without U-joint
3697704000
YS
396.6
100
M20
25
°
