Spicer WING STYLE COMPONENTS - Manual (Page 4)

Double Joint without U-Joints (H element) 3632250015 44.6 1/2" 20 UNF 15 °
Double Joint without U-Joints (H element) 3632250005 44.6 M12 15 °
Double Joint without U-Joints (H element) 3632250006 54 1/2" 20 UNF 23 °
Kit sliding shaft without tube (fix joint and slip joint) 3600001003 R 3L HWD YS 130 1/2" 20 UNF 25 ° 88x4
Kit sliding shaft without tube (fix joint and slip joint) 3600001103 R 3L HWD YS 130 1/2" 20 UNF 25 ° 88x4
Centered Double Joint with U-Joints 3612200002 R 3L HWD 204 1/2" 20 UNF 43 °
Centered Double Joint with U-Joints 3612200004 SF 3L HWD 184 1/2" 20 UNF 43 °
Legend u-joint kit style: Legend blocks style :
R = relube, with nipple RB = nipple on caps HW = high wing D = through hole T = threaded
LM = through holes with nipple hole plugged, pre-lube LW = low wing D = through hole T = threaded
SF= prelube DW= delta shape wing
Legend sealing style: Legend shaft style :
2L = two lips seal SS = sleeve yoke + stub shaft SC = short couple std. execution
3L = three lips seal YS = yoke shaft + tube sleeve SCY = short couple inverted slip
(inverted slip)
DESCRIPTION
S
IC
P
/N
U
-
J O
IN
T
S
T
Y
L
E
S
E
A
L
IN
G
S
T
Y
L
E
B
L
O
C
K
S
S
T
Y
L
E
S
H
A
F
T
S
S
T
Y
L
E
M
IN
.
L
E
N
G
H
T
[m
m
]
S
L
IP
[m
m
]
H
O
L
E
S
T H
R
E
A
D
A
N
G
.
T U
B
E
D
IM
.
m
m
206M80 - 8C
Universal Joint 2 Lips Sealing 3050A62000 R 3L HWD
Universal Joint 2 Lips Sealing 3050423000 SF 2L HWD
Universal Joint 3 Lips Sealing 3050A64000 SF 3L HWD
Slip Joint without U-Joint 3640750002 SS 256.5 76 1/2" 20 UNF 30 ° 95x7.5
Tube Yoke 3635050000 65 1/2" 20 UNF 30 ° 95x7.5
Slip Joint without U-Joint 3480000040 YS 301 130 1/2" 20 UNF 30 ° 100x6
Tube Yoke 3635050007 65 1/2" 20 UNF 30 ° 100x6
Tube (Length 1 meter) 3820950075 95x7.5
Tube (Length 1 meter) 3065580102 100x6
Bolt 3815300014 HWD 50,8-31,75 useful 1/2" 20 UNF
Central Bearing SKF Type SY 65 TF 203x76,2 3640860013
Kit sliding shaft without tube (fix joint and slip joint) 3600001108 R 3L HWD YS 130 1/2" 20 UNF 30 ° 100x6
Kit sliding shaft without tube (fix joint and slip joint) 3600001109 SF 3L HWD YS 130 1/2" 20 UNF 30 ° 100x6
Short couple without U-joint 3699530007 R SC 222.5 50 1/2" 20 UNF 30 °
Short couple without U-joint 3699530012 R SC 261.6 60 1/2" 20 UNF 30 °
Short couple without U-joint 3697765000 SC 364.4 60 1/2" 20 UNF 30 °
165M85 - 8,5C
Universal Joint 3 Lips Sealing 3050246000 R 3L HWD
Universal Joint 3 Lips Sealing 3050281000 SF 3L HWD
Universal Joint 3050964000 R 2L HWD
Universal Joint 3050261000 R 3L 2 HWD/2LWT
