8
Two-Speed-Planetary Double Reduction
Two-Speed-Planetary Double Reduction (Continued)
Qty.
Item Per 15040T 19050T
No. Description Axle 15040P 19050P Notes
44 PINION BEARING SPACER AR See page 11
45 PINION BEARING CUP - INNER 1 49849* 12495*
46 PINION BEARING CAGE SHIMS AR
0.003” 1 75968* 107567*
0.005” 1 75969* 107568*
0.010” 1 75970* 107569*
0.020” 1 75971* - NLA 107570*
0.030” 1 75972* -----
47 BEARING CAGE DOWEL PIN 1 90654 -----
48 PINION BEARING CAGE & CUP ASSY. 1 76897 75110 Incl. items 45, 50
CAGE - NSS 1 76896 75109
49 CAP SCREW 6 113325 113325
50 PINON BEARING CUP - OUTER 1 49849* 12495*
51 PINION BEARING CONE - OUTER 1 49848 33699*
KIT - OIL SEAL & SHIM 1 121800 114104
52 OIL SEAL 1 935735* 119427* 935735 is for 2.625” pinion
53 INPUT YOKE 1 See page 14
54 FLAT WASHER 1 210114 210114
54A PINION NUT 1 210133 210133
55 DIFF. CASE CAP SCREW 8 109237 109238
DIFF. CASE CAP SCREW 4 ----- 118739
KIT - WHEEL DIFF SIDE GEAR KIT 1 114467 121748
KIT - WHEEL DIFF. KIT - LESS SIDE GEAR 1 118746 121749
56 DIFF CASE - RH - NSS 1 71881 126007 Order Wheel Diff Case Kit
57 SIDE GEAR THRUST WASHER 2 127837* 126004*
58 DIFF. SIDE GEAR - 34 INV SPLINE 2 110522 -----
DIFF. SIDE GEAR - 36 INV SPLINE 2 ----- 126000
59 SIDE PINION THRUST WASHER 4 25968* 126003*
60 SIDE PINION 4 102512 126001
61 SPIDER 1 127836 126002
KIT - WHEEL DIFF CASE 1 52112 121807 Incl. items 56, 57, 63
62 DIFF. CASE - LH NSS 1 71880 126005 Order Wheel Diff Case Kit
DIFF. CASE W/CLUTCH PLATE PIN - NSS 1 408237 126006 Order Wheel Diff Case Kit
63 RTV - GASKET COMPOUND AR 107276* 107276* Not IllustratedAxle
