CHECKWEIGH BASE EN-5
4.3 Technical Specifications
BASE CKW3R CKW6R CKW15L CKW30L
Capacity (max) x Readability (d) 3 kg x 0.0005 kg 6 kg x 0.001 kg 15 kg x 0.002 kg 30 kg x 0.005 kg
6 lb x 0.001 lb 15 lb x 0.002 lb 30 lb x 0.005 lb
60 lb x 0.01 lb
Maximum Resolution 1:6000 1:7500 1:7500 1:6000
Capacity (max) x Approved Readability (e) 3 kg x 0.001 kg 6 kg x 0.002 kg 15 kg x 0.005 kg 30 kg x 0.01 kg
6 lb x 0.002 lb 5 lb x 0.005 lb 30 lb x 0.01 lb 60 lb x 0.02 lb
Approved Resolution (n max) 1:3000 1:3000 1:3000 1:3000
Linearity 1d 1d 1d 1d
Repeatability (standard deviation) 1d 1d 1d 1d
Pan Dimensions (W x D x H) 254 x 254 x 57.5 mm 305 x 305 x 57.5 mm 305 x 305 x 69.5 mm
10” x 10" x 2.26 in. 12" x12" x 2.26 in. 12" x 12" x 2.74 in.
Construction 304 Stainless Steel with Non-slip Rubber Leveling Feet
Leveling Component Externally Visible Level Indicator and Adjustable Leveling Feet
Load Cell Capacity 6 kg 10 kg 30 kg 50 kg
Load Cell Cable 1m / 3ft. L x 4-wire 1m / 3ft. L x 4-wire 1m / 3ft. L x 4-wire 2m / 6ft. L x 6-wire
Load Cell Type 350 ohm, full bridge, Stainless steel
Load Cell Excitation 5 to 15V DC/AC
Load Cell Rated Output 2 mV/V
Load Cell Protection IP67
Operating Temperature Range -10°C to 40°C / 14°F to 104°F
Relative Humidity 10% to 90%, non-condensing
Height above sea level Up to 4000 m
Safe Overload Capacity 150% of rated capacity
Product Weight 5.1 kg / 11.24 lb 6.2 kg / 13.67 lb 8.3 kg / 18.30 lb 9.3 kg / 20.50 lb
Shipping Weight 7 kg / 15.43 lb 8.1 kg / 17.86 lb 10.3 kg / 22.71 lb 11.3 kg / 24.91 lb
Food Safety Certifications NSF, USDA / AMS
Legal For Trade/Type Approval • OIML: R60/2000-NL-02.14 / TC6046 r1 – 6, 10, 30 kg load cell
R60/2000-NL1-03.24 / TC6120 r1 – 50 kg load cell
