STRUT BRACE INSTALLATION
1.
The first step for this installation is to remove the front struts to gain more room to
drill our strut brace mounting holes. There are 4 holes total that will be drilled.
Jack the front of the car up and place the car on jack stands. Remove the front
wheels.
2.
Unbolt the brake line tab from the strut.
3.
Remove the ABS line from the bracket.
BRAKE LINE
BRACKET
ABS BRACKET
