Hotchkis 2268 Hardware pack for 59-64 Rear Sway Bar User Manual
Hotchkis For the car
2268 FRONT AND REAR SPORT SWAY BAR SET
59-64 CHEVROLET B-BODY
Thank you for your purchase from our line of classic Chevrolet B-body suspension parts.
Please call us at (877) 4NO-ROLL if you have any questions regarding your Hotchkis
Performance products. Visit us online
This installation will require drilling new mounting holes in the frame for both the front and rear
sway bars
. Please read instructions carefully to avoid unnecessary drilling.
You will have to remove the pitman arm to install this sway bar!
INSTALLATION OF HOTCHKIS PERFORMANCE FRONT SWAY BAR
1)
Securely block the rear wheels of the vehicle and raise the vehicle with a jack. Support the
vehicle on jack stands. The wheels of the car should be turned straight for ease of installation.
Some vehicles do not have a stock front sway bar, so step 2 can be ignored. This installation
will also require a pitman arm puller. Use the photos below for reference.
The car shown above has power steering and a sway bar factory installed. Owners of cars without a
factory sway bar should note the position of the brackets and end link mounts, as you will be adding all
of these at a later time.
Document Outline
- INSTALLATION OF HOTCHKIS PERFORMANCE REAR SWAY BAR
- SEE NEXT PAGE FOR PARTS LIST
- UImproperly installed or installed by someone other than a qualified, licensed auto mechanic experienced in the installation and removal of suspension products;
- UImproperly serviced, misused, or modified, altered or subjected to abuse, negligence, accident or collision;
- UInstalled in any vehicle that has been modified;
- UInstalled on any vehicle that has carried loads in excess of automobile manufacturer suggested weight limits; or
- UInstalled on any vehicle that has been subject to abnormal or excessive use, including rallying, racing, or racing-type activities or off-road use.
- UDid you register the product at U0TUwww.hotchkis.netU0TU or via the mail-in warranty card within 30 days of purchase?
- UIs the product appropriate to your application?
- UDid you carefully and thoroughly read the instructions provided along with the product?
- UDo you have the original invoice or sales receipt?
- UIs the return date within 36 months from the purchase date?
- UAre you the original purchaser?
- UWas the product properly installed by a qualified, licensed auto mechanic?
- UHas the product been installed on the original vehicle on which it was installed at all times?
- UIs the product unmodified and clean?
- UIs the reason for return a legitimate product defect?
