Hotchkis 3002 1979-1993 Mustang Caster Camber Plate - Manual (Page 3)

10.) Put your end link back on.
11.)
With the Delta
 Plate hardware slightly loose slide the strut to original alignment
settings using pen marking as the guide. Then snug down and check hood clearance. Do
not close hood before checking. With one washer between the spacer sleeve and the
lower poly bushing the strut can hit the inner hood support. This setup will provide the
ultimate shock travel but will dent the inner hood support. Installing up to three spacer
washers between the spacer sleeve and lower poly bushing can move down the strut.
Lowered cars will benefit from more shock travel. Once the spacers are determined,
tighten 8mm bolts to 20 ft. lbs., and 12mm nuts to 40. Lbs.
12.) Lower jack and repeat for the other side.
13.) Test drive car and check bolt and nut tightness.
Beveled side up
Installed At Hotchkis
Washer (up to three)
Shock spacer sleeve
