Detach, Links, Unbolt sway bar bushing brackets – Hotchkis 22833R VW MKV, MKVI Rear Sport Sway Bar User Manual

Page 2: Undo, Exhaust, Hangers

background image



3F

Detach

End

Links

Loosen and remove the lower end link nuts from both sides, and push links aside.


4F

Unbolt Sway Bar Bushing Brackets

Unbolt the 4 bolts (2 per side) that secure the sway bar to the subframe.


5F

Undo

Exhaust

Hangers

Unbolt the front exhaust hanger mount
