6
8. Reconnect the knuckle assemble.
NOTE: Insert ALL ball joint connecting bolts from rear to front! If this is
not done the control arm will rub on the bolt at full steering lock.
9. Remove the stock tie rod end and connect the new heim joint provided.
10. To connect the new heim joint to the knuckle assembly you will need to use a ½”
drill bit and drill a larger hole where the tie rod connects to the knuckle.
11. Once you have drilled the hole, use the ½ x 3 1/4” hex bolt and the two high
alignment bushings and connect the heim joint to the knuckle.
