Issue 1.0.E XFly Streamer – Version 1.00 – User Manual
EVS Broadcast Equipment – April 2012 –Author: Marianne Lothaire
14
Area Description
4. Channels Pane This area shows the server Recorder channels
which are selected in the servers’ list.
5. Commands &
Status
This area displays the Timecode reference and
duration, the status and the 2 main commands to
start and stop the recordings.
On the top left of the window, a message mentions the version number of the
application. There is no menu bar.
7.2 STORAGE & PROCESSING DEVICES
SELECTION
Thanks to BONJOUR protocol, at start-up, XFLY systems are detected and listed
in a drop-down list.
Clicking on the arrow on the right will display all systems detected. In the drop-
down list, XFly is identified as Machine_Name + EVS_SN.
Note
The local device is displayed on the top of the list with bold letters.
Once a system is selected its capacity information and a related diagram are
updated:
The second drop-down list lists all XTAccess detected on the local network via
BONJOUR protocol.
Clicking on the arrow on the right will display all processing devices detected. In
