XFly Streamer – Version 1.00 – User Manual
EVS Broadcast Equipment – April 2012 – Author: Marianne Lothaire
Issue 1.0.E
13
7. User Interface
7.1 OVERVIEW
The XFly Streamer user interface consists of five main areas. They are highlighted
on the following screenshot and shortly described in the table below:
Area Description
1. Storage &
Processing
Devices Selection
From this area, the operator can selected the
storage device to store the AV files and also the
processing device i.e. the XTAccess to process
the different tasks for grabbing thumbnails and for
recording streams
2. Servers List This area displays the list of all servers detected
on the network.
3. Settings The settings area gives access to the selection of
file format, folders to save the AV files, auto
naming function and the maximum duration for
recording.
