QUICK REFERENCE GUIDE QUICK REFERENCE GUIDE
Headset operation
Activate the headset
mode Key Headset
Í
during 5 seconds
Deactivate the
headset mode Key LSP
Â
during
5 seconds
Answer calls - mode
headset activated Key Lx
Ц Ф
of the
call presented
End of call Key C
Make calls - mode
headset activated Free key Lx
Ô
+
No. + Call
Switch headset
mode -> handset Lift handset
u
Switch handset ->
headset mode Key Headset
Í
and
replace handset
Switch headset
mode -> handsfree Key LSP
Â
Switch handsfree ->
headset mode Key Headset
Í
Headset volume Keys
ì
Telephone keys
Navigation keys: Left, Home,
Right
Bottom line of
LCD display Dynamic function keys (4):
Log on, Call, Select …
Fixed function keys (5):
Menu, Name, Call-Fwd,
Message, Transfer
Line keys (3): Lx
Repertory keys (12): Rx
Key C - Clear
Key Headset
Key LSP - Loudspeaker
Key Mute
Keys +/- - Ringer or
loudspeaker volume setting
Icons on the LCD display
Icon Function Description
Home First screen page in
set idle mode (Home)
Volume
level bar
Indicates the ringer
volume or the
loudspeaker volume
Silent
ringing
Signals that silent
ringing is activated
Call List Signals an incoming
call missed not
consulted
Call List Signals an incoming
call missed consulted
Call List Signals an incoming
call answered
Call List Signals an outgoing
call
Bar
indicator
Signals a menu list too
long to be displayed on
a single screen and
shows position in list
Option
button
Signals the option
selected in a list
Option
button
Signals an option not
selected in a list
Menus configuration
hone displays the 5
th the navigation
s Follow the menu
The upper line of the telep
main menus: Settings, Call List, Home,
PhoneBook and WAP Services.
Select the wanted menu wi
keys Left and Right, and then progress in the
menu with the 4 dynamic keys displayed on
the bottom line of the screen.
Settings
Programmable key
Ringing melody
Follow the menu
Time & Date form
Example - Programming the programmable
Repertory keys:
ats Follow the menu
Language Not applicable
Display contrast Select contrast
Log off restriction Not applicable
Hearing level LSP Select level
Key Left twice + Select + key Rx to program +
extension No. or prefix and external No. or
service code + Save + key Home
Call List
The telephone stores a list of 50 calls including
the missed incoming calls - new or already
consulted, the answered incoming calls, and
the outgoing calls.
Selection of Call List
Key Right or
n Missed
Scroll the call list n times Þ or Û
Transfer a call number to
the PhoneBook more… +
AddPhoneBook
Erase a call more… + Delete
Return to the call list more… + Back
Exit from Call List Exit or key Home
To be noted that upon a power shortage or
upon Free seating, the call list is erased.
PhoneBook
The telephone accommodates a centrally
stored phone book of up to 100 names +
numbers. You can enter a couple name +
number from the digital keypad, modify or
delete an entry, or add a call from the Call List.
To enter a name/number from the keypad,
press 1/2/3 times the key 2-9 for displaying the
1st/2nd/3rd letter associated to the key. Press
the key * to switch between upper and lower
cases. Press the dynamic key Erase to correct
a wrong entry.
Examples:
Selection of PhoneBook
Key Right
To enter S in upper case 7777
To enter m in lower case 6*
To enter i in lower case 444
To enter t in lower case 8
To enter h in lower case 44
Declaration of Conformity
Hereby, Aastra Telecom Sweden AB, S-126 37 Hägersten,
declaresthat this telephone is in conformity with the essential
requirements and other relevant provisions of the R&TTE
directive 1999/5/EC. Details to be found at:
http://www.aastra.com/sdoc
ì
Add a name + number in the PhoneBook
Select PhoneBook
Key Right
Select Add 3 times Þ + Select
Enter a name See above (max. 24
characters)
Validate Save
Enter a number n digits (max. 18)
Validate and confirm Save + OK
Return general menu Back
Exit PhoneBook Exit or key Home
Modify a name + number in the PhoneBook
Select PhoneBook
Key Right
Select Edit Þ + Select
Search a name Enter the first letter(s)
of the name + Search
+ n times
Þ or Û to
frame wanted name
Select name in frame Edit
Change or enter a
name Erase and enter
letter(s) with keypad
Change the number Number + Erase and
enter digits
Validate name +
number Save + OK
Return general menu Back
Exit PhoneBook Exit or key Home
Subject to alteration without notice
For questions regarding the product,
please contact your Aastra Certified Sales Partner.
Also visit us on: www.aastra.com
© Aastra Telecom Sweden AB 2008. All rights reserved.
EN/LZTBS 102 1942 R3A
