Palm Rest
Dell™ XPS™ M1730 Service Manual
Removing the Palm Rest
Replacing the Palm Rest
Removing the Palm Rest
1. Follow the instructions in Before You Begin .
2. Remove any installed ExpressCards from the ExpressCard slot.
3. Remove any installed memory modules or Mini Cards (see Memory and Communication Cards ).
4. Remove the hard drive (see Hard Drive ).
5. Remove the display assembly (see Display Assembly ).
6. Turn the computer upside down and remove the fourteen screws from the computer base.
7. Turn the computer top side up and remove the nine screws marked P from the top of the palm rest.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
1 touch pad cable
