GPSMAP 3005C Owner’s Manual
u
sIng
r
AdAr
> M
AP
P
Age
r
AdAr
o
verlAy And
r
AdAr
t
Ab
Map Page Radar Overlay
Radar information can be shown as an overlay on the Map Page. When you
overlay radar information on the Map Page, you can press ADJ/MENU to access
many of the radar options.
NOTE: Changing the map scale does not change the radar range. When you
zoom in or out on the Map Page, the radar overlay is scaled to fit.
To overlay radar data on the Map Page:
On the Map Page, press the Show Radar soft key.
Map Page with Radar Overlay and Radar Page
To hide the radar data overlay on the Map Page:
1. Press the Radar Options soft key.
2. Press the
Hide Radar soft key. The radar overlay is hidden.
Radar Tab
When a GMR 20/40, GMR 21/41, or GMR 404/406 marine radar is connected to
the GPSMAP 3005C, and either the Auto-Detect Services or Radar check box is
selected on the System tab, the Radar tab appears on the Main Menu.
Use the Radar tab to set up the Radar Page. The Radar tab has four sub tabs:
General, Display, MARPA, and Advanced.
To access and change a setting on the Radar tab:
1. Press the Setup soft key on the Radar Page to open the Main Menu. The
Radar tab is automatically selected.
2. Highlight the setting you want to change, and then press ENTER.
3. Press QUIT to return to the Radar Page.
