Setup

DRO 200T

Setup

The

SETUP

key lets you change the system parameters. Some of these parameters

are job related, meaning that they may change from job to job. Others are
machine related and should be set as part of the installation. The machine-related

parameters can be accessed by pressing:

Use the

key to move from one parameter to the next. After the last

parameter, the

key ends the setup process and saves any changes. Use the

CLEAR

key to move back to a previous parameter.

Some parameters have choices. Use the

key cycle through the available

choices.

At any time during setup, pressing the

SETUP

key will end the setup process and

save the changes.

Machine-Related Setup Parameters

Count Direction

This determines which way is positive. Move each axis in the positive count
direction. The display will show a 1 or a 2 depending on count direction. You can
also change the count direction by pressing the

key.

Encoder Resolution

Move each encoder until the readout senses and displays the resolution. You won’t
have to move more than two inches. For scales without Position-Trac, you need to
enter the encoder resolution. You can press the

key to select from common

choices, or you can use the keypad to enter the resolution directly.

SETUP

ENTER

Access Code
