ACU-RITE Microscale User Manual
Page 3
Page
Introduction / Supplied items ................................................... 2
Key Points / Tolerances ............................................................. 3
Linear Encoder Dimensions ...................................................... 4
Spar Dimensions ....................................................................... 5
Mounting Requirements ........................................................... 6
Typical Mounting ...................................................................... 7
Encoder Installation Procedure ................................................. 8
Page
Checking the Installation ......................................................... 10
Troubleshooting ....................................................................... 11
Mechanical Specifications ....................................................... 12
Output Signals and Pin-Outs ................................................... 13
Electrical Specifications .......................................................... 14
The ACU-RITE warranty and
30-Day Red Carpet warranty service ....................................... 15
MicroScale
Table of Contents
• Installation brackets and kits are available.
• Your Authorized ACU-RITE Distributor can assist you in selecting
brackets and tools for your installation.
1
ACU-RITE
®
Front mount
bracket
Adjustable
front mount
Bottom mount
bracket
Base mount
Rear mount
bracket
