Mechanical Specifications MicroScale
Mechanical Specifications Digital Analog
Resolution 0.5µm 1µm 5µm
Grating pitch 20µm
Scale medium Light transmission through chrome-coated glass
Accuracy (@ 20° C) / 1000mm ± 3µm, ± 5µm
Connecting cable Length = 5, 10, 15, and 20 ft. Length = 2, 5, 10, 15, and 20 ft.
armored or vinyl Connector: DE-9P or Bendix PTO 6A-10-6P Connector: DE-9P
(or Cannon, Burndy equivalent)
Max. cable length (ft) 36 26
Repeatability Within one resolution count
Reference pulse interval 100mm fixed or Position Track
Measuring lengths 1” - 60”
Weight (lbs) 1.1 + 0.12/ft of measuring length
Force required to move < 0.5 (lbs)
reading head
Max. slew speed (inches/sec)
@ 10° C to 30° C
40
@ 0° C to 40° C 21
Operating Environment
Temperature
0° to 40° C
Relative Humidity 20% to 95% (non-condensing)
Storage Environment
Temperature
- 40° to 65° C
Humidity 20% to 95% (non-condensing)
