AcuTab 2 Manual
4. Attach the Barcode Scanner connector to the connectors inside
the compartment.
5. Screw to secure the Barcode Scanner module onto the system.
Barcode Scanner Module
3.
7 . Using a MSR Module (optional)
Your AcuTab 2 is designed with equipped the optional MSR
module.
Before installing the barcode scanner module, please switch the DIP
47
