Acura Embedded PowerBrick ATOM User Manual
Powerbrick, Atom™ quick manual

PowerBrick - ATOM™ Quick Reference Manual
Copyright by Acura Embedded Systems Inc. Updated by August 09/13
PowerBrick
ATOM™
Quick Manual
Small footprint rugged Intel® ATOM™
Industrial Computer
1. Overview
The PowerBrick - ATOM™ is an Intel® Atom™ dual core D2550 with 1.86 GHz
processor speed. This small, rugged and powerful computer is the premium
choice when desktop computer performance is required in industrial computing
applications. Small size does not necessarily mean limitations in computing
power.
The state-of-the-art PowerBrick - ATOM™ comes loaded with an impressive
video card, fast hard drive (optionally SSD HDD drive) and memory, all at a
competitive price. It is designed and built for great performance in a variety of
applications and environments. The design focuses on elements essential for
industrial use wile excluding unneccesary hardware. The architecture is modular
which allows for easy upgrading and expansions.
Areas of applications include:
•
Oil-rigs/Gas/Mining vehicles
•
Security and patrol vehicles even helicopters
•
Emergency ( EMS) or public safety vehicles
•
Seaport terminal container yard management
•
Fleet management
The main features are:
Figure 1.1: Front side of PowerBrick ATOM™
•
On-board Intel® Atom™ Dual Core D2550 processor, 1.86 GHz
•
Intel® NM10 Express chipset
•
1x DDR3 SO-DIMM sockets, support up to 4G DDR3-800/1066
SDRAM, un-buffered and non-ECC
•
6x USB2.0 ( 2x front side and 4x back side)
•
2x RS232/422/485(Com2,3 and 2x RS232 Com1,4)
Page 1
