SECTION 6—OPERATING INSTRUCTIONS
Part No 1148112 27 Invacare XPO
2
™
Powering the XPO
2
NOTE: Both the internal and supplemental battery require full
charging prior to first use. Refer to Charging the Batteries on
page 22.
NOTE: For this procedure, refer to FIGURE 6.6 on page 28.
1. The XPO
2
allows the freedom to choose from the following
power sources:
• The internal battery. The XPO
2
comes equipped with
an internal battery that is installed at the factory and is
not user serviceable.
• The supplemental battery pack. To use, connect the
supplemental battery pack to the XPO
2
as shown in
Detail “A”.
• A DC power outlet (i.e. an automobile). To use, connect
the DC power adapter to the XPO
2
as shown in Detail
“B”. Connect the other end of the DC power adapter to
the DC power source.
• An AC outlet (i.e. wall outlet of your home). To use,
connect the AC power adapter to the XPO
2
as shown in
Detail “C”. Connect the other end of the AC power
adapter to the AC power outlet.
2. If the XPO
2
is in use and connection to an external power
supply is necessary, perform the following:
A. Turn off the XPO
2
.
B. Connect the external power supply (e.g. supplemental
battery pack, DC mobile power adapter, or AC power
adapter) to the XPO
2
.
C. Turn the XPO
2
on.
