Page 70

ACR ELECTRONICS, INC / ARTEX PRODUCTS
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
G406-4 (453-5012)
25-62-21
Page 70 of 86
JUL 31/12
SUBTASK 25-62-21-450-008
I.
Airframe Ground Connections
(1)
Connect the ground wires to the airframe in accordance with the aircraft manufacturer’s
written instructions or as described in AC 43.13-1, Chapter 11, § 15, as applicable. See "Figure
19. Remote Switch Harness Wiring Diagram”, on page 66.
SUBTASK 25-62-21-450-009
J.
Buzzer Connections
(1)
Connect the power wire to the buzzer positive (+) terminal.
(2)
Connect the ground wire to the buzzer negative (–) terminal.
SUBTASK 25-62-21-450-010
K. Remote Switch Final Installation
(1)
Insert the harness plug into the remote switch receptacle.
(2)
Install the remote switch assembly in accordance with SUBTASK 25-62-21-450-002, on
page 62.
