Figure 5. antennas – ACR&Artex G406-4 ELT User Manual
Page 30
ACR ELECTRONICS, INC / ARTEX PRODUCTS
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
G406-4 (453-5012)
25-62-21
Page 30 of 86
JUL 31/12
(5)
The principal antennas designed for use with the G406-4 ELT include a dual input rod antenna
and separate 121.5/243.0 MHz and 406 MHz single input whip antennas. Selection of the dual
input rod antenna or the separate whip antenna combination is dependent upon end use,
aircraft configuration and speed, and other factors. See "Figure 5. Antennas".
Figure 5. Antennas
110-320
110-324
(121.5/243.0 MHz)
110-329
(406 MHz)
