ACR&Artex G406-4 ELT User Manual
Page 59
25-62-21
Page 59 of 86
JUL 31/12
ACR ELECTRONICS, INC / ARTEX PRODUCTS
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
G406-4 (453-5012)
(6)
Install the mounting tray with the 8-32 x 5/8” SS pan head phillips screws, flat washers, lock
washers, and nuts provided in the installation kit (455-7421), as shown in "Figure 13. Typical
Mounting Tray Installation". Torque to 12 ±1 lb-in (136 ± 11 N•cm).
NOTE: The use of substitute mounting hardware is acceptable provided the hardware used
meets or exceeds the strength and corrosion resistance of the original hardware.
