ARTEX PRODUCTS / ACR ELECTRONICS, INC
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
ME406 (453-6603), ME406HM (453-6604)
25-62-30
Page 66 of 84
May 03/13
SUBTASK 25-62-30-450-009
J.
Buzzer Connections
(1)
Connect the power wire to the buzzer positive (+) terminal.
(2)
Connect the ground wire to the buzzer negative (–) terminal.
SUBTASK 25-62-30-450-010
K. Remote Switch Final Installation
(1)
Insert the harness plug into the remote switch receptacle.
(2)
Install the remote switch assembly in accordance with SUBTASK 25-62-30-450-002 on
