Chapter 1 System
1.1 Specifications
PC 9070 PC 9080 PC 9120 PC 9150
System
CPU Atom Cedar View N2600 1.6GHz Dual Core Processors
System Chipset NM10
Sys tem Memory Onboard DDR3 2GB 800 MHz
IO Port
USB 2 x USB 2.0 type A, USB4/5
Serial/Parallel 1 x RS-232/422/485 DB-9, COM1, Default RS-232
1 x RS-232 DB-9, COM2
Audio 1 x Line out phone jack
LAN 2 x GbE RJ -45
Power 3 pins terminal block connector, DC Power input
Storage Space
HDD 1 x 2.5” SATA 2 half size 1 x 2.5” SATA 2
Movable device 1 x Internal SD slot 1 x Internal SD slot
Expansion
On board
expansion bus
1 x Mini-PCIe half size
Display
Display Type 7” TFT-LCD 8”TFT-LCD 12.1”TFT-LCD 15”TFT-LCD
Max. Resolution 800x480 800x600 800x600 1024x768
Max. Color 262K 16.2M 16.2M 16.2M
Luminance
(cd/m²)
350 350 330 400
View
angle(H°/V°)
140/110 140/125 160/140 160/145
Touch screen
Type Resistive Touch / Projected Capacitive Touch (Option)
Interface RS-232 / USB
Light
Transmission (%)
80% / 90%
