4-bit digital Input
4-bit digital Output
4-bit digital I/O Pin header via CN3
2-bit digital Input
2-bit digital Output
Battery Support CR2477 Li battery by 2-pin header
Audio Realtek ALC662 HD audio codec
Line-in, Line-out, MIC via 2x6-pin header
Audio Line out in phone jack
Ke yboard
/Mouse
1 x PS2 keyboard/mouse 1x6 box pin header via CN3
Expansion Bus 1 x mini-PCI-express slot
1 x PCI-express via CN3
Touch Ctrl 1 x Touch control header for TCH1 (COM4)
Pow er
Management
Wide Range DC 9~36V input
1 x 3-pin power input connector
Sw itches and
LED Indicators
1 x Powe r on/off switch via CN1
1 x Reset switch via CN1
1 x Power LED status via CN 1
1 x HDD LED status via CN1
1 x Buzzer
External I/O
port
2 x COM Ports (COM1/CO M2)
2 x USB 2.0 Ports (U SB4/USB5)
2 x GbE LAN Ports
1 x Line out Audio phone jack
Watchdog
Timer
Software programmable 1
– 255 second by Super I/O
Temperature
O perating: -20 to 70
Storage: -40 to 85
Humidity 5% - 95%, non-condensing, operating
Pow er
Consumption
12V /0.95A ( Intel Atom N2600 processor with 2GB DDR3
DR AM)
EMI/EMS Meet CE/FCC class A
