13 . External L G igabyte Ether ne t Port 1 & Port 2 [Board Location: J11 & J13]
Internal LAN Port 1 & L AN Port 2 Connector [B oard Location: J1 2 &J14]
PIN Sig nal PIN S ignal
1 LNA_TX1+ 2 LNA_TX1-
3 LNA_TX2+ 4 LNA_TX3+
5 LNA_TX3- 6 LNA_TX2-
7 LNA_TX4+- 8 LNA_TX4-
14 . External DV I 1 & DV I 2 [Board Location: J15 & J18 ]
15 . Internal GPIO (Low Active) [Boa rd Location: J2 2]
PIN Sig nal
1 +5V
2 DI 0
3 DI 1
4 DI 2
5 DI3
6 DI4
7 DI5
8 DO 0
9 DO 1
10 GND
16 . Internal COM 5, COM 6 Connector [Board Location: J29, J31 ]
PIN RS-232
1 DCD
2 DSR
3 RXD
4 R TS
5 TXD
6 CTS
7 DTR
8 RI
9 GND
10 +5V
