Chapter 2: Pin Definition & Jumper Settings
2-1 2230 Front panel Pin Definition
1. Power On/Off & Reset B utton
2. Power & HDD Led
3. 2 optional W iFi ante nna
2-2 2230 Rear Panel Pin Definition
1. USB Connector
PIN Sig nal PIN Sig nal
1 5V 5 5V
2 D- 6 D-
3 D+ 7 D+
4 G ND 8 GND
2. LAN 1 & 2 (RJ-45)
PIN Definition PIN D efi niti on
1 Lan_T X1+ 2 Lan_T X1-
3 Lan_T X2+ 4 Lan_TX3+
5 Lan_TX3- 6 Lan_T X2-
7 Lan_T X4+ 8 Lan_T X4-
3. DVI-D: J1 8 DV I 2 ( DVI-D ) connector
4. DVI-I: J15 DV I 1 ( DVI-I ) connector
