Chapter 3 – Setting up the RAID box
21
Loading drives in the RAID box
All three hard disks should be configured as Master
(only for ACS -76500).
There are two types of drive carrier available for ACS-76500 controller:
Fixed IDE connector
Drive Carrier
Fixed IDE Connector
Power Connector
There is one type of drive carrier available for ACS-76510 controller.
Fixed SATA connector
Drive Carrier
Fixed SATA Connector
Power Connector
