Acclaim Lighting AL Driver 8-RGBW 24V User Manual
Page 2
Table of Contents
1. General Information..................................................................1
1.1. Unpacking..........................................................................1
1.2.Safety warnings..................................................................1
2. Main features............................................................................2
3. DMX setup................................................................................2
4. Product layout & functions........................................................3
4.1.Front panel layout..............................................................3
4.2.Rear panel layout...............................................................4
5. Operation guide........................................................................4
5.1.DMX control mode(DMX address setting)..........................4
5.2.Stand alone mode..............................................................5
5.2.1.Fade time setup........................................................5
5.2.2.Chase speed adjusting.............................................5
5.2.3.Selecting built-in programs........................................5
5.2.4.Output mode setting..................................................6
6. Appendix-
(RGB) Color Mix and DMX value Table....................................7
7. System connection diagram...................................................12
8. Technical specifications..........................................................14
-13-
No. Of units / 24VDC,6.5A power supply
X-CHIP-W15 - Amber
X-CHIP-W12 - 6000K
X-CHIP-W12 - 3200K
X-CHIP-W12 - Amber
X-CHIP-II
120
150
150
150
84
X-CHIP-100 DIP
X-CHIP-100 SMD
X-CHIP-300 DIP
X-CHIP-300 SMD
X-CHIP-W15 - 6000K
X-CHIP-W15 - 3200K
120
MODEL
QTY.
120
120
120
120
120
MODEL
QTY.
AL-Driver-8RGBW
DMX IN
DMX OUT
100-240VAC
INPUT
Standard DMX cable
length 300m Max.
X-CHIP-W12 first cable
length 0.5~5m
2-color Flat-cable
length 100mm
Up to 150pcs X-CHIP-W12 per port, total 150pcs per AL-Driver-8RGBW
DMX IN
DMX OUT
1
2
3
4
5
6
7
8
X-CHIP-W12 First Cable
+24V
Red
Green
Blue
White
2
4
V
G
N
D
2
4
V
G
N
D
* Black cable (GND) shall be connected
to Red / Green / Blue / White(-).
2.AL-Driver-8RGBW with X-Chip-W12
Note: when the AL-Driver-8RGBW is used to drive X-Chip-W12(s), only the WHITE mode and
the RGB&WHITE mode are valid, and other modes are not available.
