www.Stiebel-eltron.CoM PSH UniverSal el| 35
16.4 data table
PSH 30
Universal el
PSH 50
Universal el
PSH 80
Universal el
PSH 100
Universal el
PSH 120
Universal el
PSH 150
Universal el
231150 231151 231152 231153 231649 231154
Hydraulic data
Nominal capacity
l 30 50 80 100 120 150
Mixed water volume 40 °C (15 °C/60 °C), vertical l 53 92 136 183 217 273
Mixed water volume 40 °C (15 °C/60 °C), horizontal l 42 76 111 153 173 194
Electrical data
Connected load ~ 230 V
kW 2.6 3 3 3 3 3
Rated voltage V 230 230 230 230 230 230
Phases 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE
Frequency Hz 50 50 50 50 50 50
Single circuit operating mode X X X X X X
Dual circuit operating mode X X X X X X
Manual operating mode X X X X X X
Heat-up time 2.6 kW (15 °C/60 °C) h 0.61
Heat-up time 3.0 kW (15 °C/60 °C) h 0.88 1.42 1.77 2.13 2.66
Application limits
Temperature setting range
°C 7-85 7-85 7-85 7-85 7-85 7-85
Max. permissible pressure MPa 0.6 0.6 0.6 0.6 0.6 0.6
Max. flow rate l/min 23.5 23.5 23.5 23.5 23.5 23.5
Energy data
Standby energy consumption/24 h at 65 °C, vertical
kWh 0.57 0.78 0.88 1.05 1.19 1.29
Standby energy consumption/24 h at 65 °C, horizontal kWh 0.83 0.94 1 1.26 1.43 1.57
Versions
IP rating vertical
IP25 IP25 IP25 IP25 IP25 IP25
IP rating horizontal IP24 IP24 IP24 IP24 IP24 IP24
Sealed unvented type X X X X X X
Power cable X X X X X X
Power cable length mm 1000 1000 1000 1000 1000 1000
Colour white white white white white white
Dimensions
Height
mm 676 931 893 1045 1200 1435
Width mm 380 380 475 475 475 475
Depth mm 380 380 475 475 475 475
Weight
Weight (full)
kg 52 78 114 138 163 202
Weight (empty) kg 22 28 34 38 43 52
inStallation | warranty | environMent and reCyCling
SPeCifiCation
warranty
environMent and reCyCling
Warranty
The warranty conditions of our German companies do not
apply to appliances acquired outside of Germany. In countries
where our subsidiaries sell our products, it is increasingly the
case that warranties can only be issued by those subsidiaries.
Such warranties are only granted if the subsidiary has issued
its own terms of warranty. No other warranty will be granted.
We shall not provide any warranty for appliances acquired in
countries where we have no subsidiary to sell our products.
This will not affect warranties issued by any importers.
Environment and recycling
We would ask you to help protect the environment. After use,
dispose of the various materials in accordance with national
regulations.
