51
Ping of Death Protections from Ping of Death attack
Discard Ping From WAN The router’s WAN port will not respond to any Ping requests
Port Scan Protection the router from Port Scan.
Sync Flood Protection the router from Sync Flood attack.
Click at the bottom of the screen to save the above configurations. You can now configure other advance
sections or start using the router (with the advance settings in place)
2.7.4 DMZ
If you have a local client PC that cannot run an Internet application (e.g. Games) properly from behind the NAT firewall,
then you can open the client up to unrestricted two-way Internet access by defining a DMZ Host. The DMZ function
allows you to re-direct all packets going to your WAN port IP address to a particular IP address in your LAN. The
difference between the virtual server and the DMZ function is that the virtual server re-directs a particular service/Internet
application to a particular LAN client/server, whereas DMZ re-directs all packets (regardless of services) going to your
WAN IP address to a particular LAN client/server.
Note: The priority of FTP/HTTP server in DMZ is higher than that in NAS.
Parameters Description
Enable DMZ
Enable/disable DMZ
Note: If there is a conflict between the Virtual Server and the DMZ setting, then Virtual
Server function will have priority over the DMZ function.
Public IP Address
The IP address of the WAN port or any other Public IP addresses given to you by your
ISP
Client PC IP Address
Input the IP address of a particular host in your LAN that will receive all the packets
originally going to the WAN port/Public IP address above
Note: You need to give your LAN PC clients a fixed/static IP address for DMZ to work
properly.
2.8 Print Server
The router USB ports provide Print Server function to share printers for the network users. It supports LPD and IPP
printing protocol.
