44
Comment The description of this setting.
Popular applications
This section lists the more popular applications that require multiple connections. Select
an application from the Popular Applications selection. Once you have selected an
application, select a location (1-10) in the Copy to selection box and then click the Copy
to button. This will automatically list the Public Ports required for this popular application
in the location (1-10) you’d specified.
Add Special Application
Fill in the "Trigger Port", "Trigger Type”, “Public Port”, "Public Type", "Public Port" and
"Comment" of the setting to be added and then click "Add". Then this Special Application
setting will be added into the "Current Trigger-Port Table" below. If you find any typo
before adding it and want to retype again, just click "Clear" and the fields will be cleared.
If you want to add a popular application, select one “Popular Application” and then click
“Add”.
Remove Special
Application
If you want to remove some Special Application settings from the "Current Trigger-Port
Table", select the Special Application settings you want to remove in the table and then
click "Delete Selected". If you want remove all Special Applications settings from the
table, just click "Delete All" button. Click "Reset" will clear your current selections.
Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance
sections or start using the router (with the advance settings in place)
Example: Special Applications
If you need to run applications that require multiple connections, specify the port (outbound) normally associated with
that application in the "Trigger Port" field. Then select the protocol type (TCP or UDP) and enter the public ports
associated with the trigger port to open them up for inbound traffic.
Example:
ID
Trigger
Port Trigger
Type Public
Port Public
Type
Comment
1 28800 UDP
2300-2400,
47624
TCP
MSN Game
Zone
2 6112 UDP 6112 UDP Battle.net
In the example above, when a user trigger’s port 28800 (outbound) for MSN Game Zone then the router will allow
incoming packets for ports 2300-2400 and 47624 to be directed to that user.
Note: Only one LAN client can use a particular special application at a time.
2.6.4 UPnP Settings
With UPnP, all PCs in you Intranet will discover this router automatically. So you do not have to do any configuration for
your PC and can access the Internet through this router easily.
