41
Parameters Description
Enable Port Forwarding Enable Port Forwarding
Private IP
This is the private IP of the server behind the NAT firewall.
Note: You need to give your LAN PC clients a fixed/static IP address for Port Forwarding
to work properly.
Type
This is the protocol type to be forwarded. You can choose to forward “TCP” or “UDP”
packets only or select “both” to forward both “TCP” and “UDP” packets.
Port Range The range of ports to be forward to the private IP.
Comment The description of this setting.
Add Port Forwarding
Fill in the "Private IP", “Type”, “Port Range” and "Comment" of the setting to be added and
then click "Add". Then this Port Forwarding setting will be added into the "Current Port
Forwarding Table" below. If you find any typo before adding it and want to retype again,
just click "Clear" and the fields will be cleared.
Remove Port Forwarding
If you want to remove some Port Forwarding settings from the “Current Port Forwarding
Table", select the Port Forwarding settings you want to remove in the table and then click
"Delete Selected". If you want remove all Port Forwarding settings from the table, just click
"Delete All" button. Click "Reset" will clear your current selections.
Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance
sections or start using the router (with the advance settings in place)
2.6.2 Virtual Server
Use the Virtual Server function when you want different servers/clients in your LAN to handle different service/Internet
application type (e.g. Email, FTP, Web server etc.) from the Internet. Computers use numbers called port numbers to
recognize a particular service/Internet application type. The Virtual Server allows you to re-direct a particular service port
number (from the Internet/WAN Port) to a particular LAN private IP address and its service port number. (See Glossary
for an explanation on Port number)
