8
2 Hardware Installation
2.1 Connecting the ADSL Router
Step 1 Connect the ‘Line’ port of the device and the ‘Modem’
port of the ADSL splitter with a telephone cable.
Connect the phone to the ‘Phone’ port of the splitter
through a telephone cable. Connect the incoming line
to the ‘Line’ port of the splitter.
The splitter has three ports:
Line: Connect to the phone port on the wall
(RJ-11 jack).
Modem: Connect to the DSL port of the device.
Phone: Connectto a telephone set.
Step 2 Connect the LAN port of the device to the network
card of the PC through an Ethernet cable
(MDI/MDIX).
Note:
Use twisted-pair cables to connect with the Hub or switch.
Step 3 Plug one end of the power adapter to the wall outlet
and connect the other end to the Power port of the
device.
Connection type 1: Figure 3 shows the application diagram
for the connection of the device, PC, splitter and telephone
sets, when no telephone set is placed before the splitter.
