5. Supported Resolution
If the SOURCE LED continues to blink in blue (slower than “no signal” mode); OSD display: “No
Supported Format” and there is no video displayed or the video quality suffers, it indicates that the
video frame rate from your A/V source device is not supported. Ensure that the consumer timing of
your HD device is compliant with the standard listed below:
Video Format Timings Resolution Supported
Primary CEA Video Timing
640x480p @ 59.94 / 60Hz
480p
YES
720x480p @ 59.94Hz YES
720x480p @ 60Hz YES
720x576p @ 50Hz 576p YES
1280x720p @ 50Hz
720p
YES
1280x720p @ 59.94 / 60Hz YES
1920x1080i @ 50Hz
1080i
YES
1920x1080i @ 59.94 / 60Hz YES
1920x1080p @ 50Hz
1080p / 60
YES
1920x1080p @ 59.94 / 60Hz YES
Secondary CEA Video Timing
1920x1080p @ 23.98 / 24Hz
1080p / 24
YES
1920x1080p @ 25Hz YES
1920x1080p @ 29.97 / 30Hz YES
VESA Timing (DVI only)
640x480 @ 59.94 / 72.809Hz VGA YES
800x600 @ 60.317 / 72.188Hz SVGA YES
1024x768 @ 60 / 70.069Hz XGA YES
1280x768 @ 60 Hz WXGA YES
1280x1024 @ 60 Hz SXGA YES
1600x1200 @ 60Hz UXGA YES
