(6) If all operation is normal, the POWER LED and INFO./CHANNEL LED will glow in solid blue.
Please refer to the next form containing detailed LED description :
Note:
A. Make sure the display for your HDMI‐ready computer connected to the WD‐1000TX has
already been turn on the external display. Please see the Chapter4.1 for the detail
operation.
B. Warming‐up or source switching time should take approximately 15~20 seconds if the
operation is in normal condition.
(7) TRANSMITTER/RECEIVER Status Indicator LED Light and OSD :
a. Status indicator LED light on the front display the following messages:
Power LED
INFO./Channel
LED
Mode Status Description OSD Display
Static Purple
on RX
Static Red on
TX
off Listen
User does not need to
press RX power key for
system wake up. TX
will wake up RX
automatically when it
boots up.
▃▆█ HDMI CH10 1280x1024
Standby Mode
Static Red Off Standby
For lower power saving
used.
▃▆█ HDMI CH10 1280x1024
Standby Mode
Blinking Blue Blinking
Booting
or
Linking
System initialize
Or
RF linking (Note A)
HDMI CH
Searching available channels…..
Static Blue
Blinking
3 times /sec.
(Quickly)
Linked
No input detected
from selected source.
(Note B)
▃▆█ HDMI CH
No Signal
Blinking
1 time / sec.
(Slowly)
Video frame rate or
resolution cannot be
recognized. (Note C)
▃▆█ HDMI CH
Not Supported Format
Static Blue
Video frame rate or
resolution is
recognized.
Transmission is
available with stable
RF signal.
