16
(8) TRANSMITTER/RECEIVER Status on OSD vs. buttons:
X Press the POWER button on the top of Transmitter (or Receiver) to enter “Standby mode” from
“active mode”.
OSD Displayed :
▃▆█ HDMI CH10 1280x1024
Standby Mode
Y Press the INFO./ CHANNEL button on the top of Receiver, the Signal Quality, Source, Channel
and resolution will be displayed for user reference.
OSD Displayed :
▃▆█ HDMI CH10 1280x1024
Press again to exit the OSD
ZPress the INFO./ CHANNEL button on the top of Receiver to manually switch wireless channels
if the user experiences video noise.
Keep press “INFO./Channel” button over 3 seconds for current Channel status displayed on
the OSD :
▃▆█ HDMI [CH10] 1280x1024
Press again to change Channel
Press the “INFO./Channel” button again within 5 seconds to switch Channel manually.
▃▆█ HDMI [CH 8] 1280x1024
Press again to change Channel
