points in an ATM network, and its valid value is from 0
to 255

VCI

The virtual channel between two points in an ATM
network, ranging from 32 to 65535 (1 to 31 are
reserved for known protocols)

Encapsulation

Choices are LLC and VC-Mux.

Channel Mode

There are five choices: 1483 Bridged, 1483 MER,
PPPoE, PPPoA and 1483 Routed.

Admin Status

If select Disable, this PVC will be unusable.

Enable NAPT

Select it to enable the NAPT functions of the MODEM.
If you are not to enable NAPT and intend the user of
the MODEM to access the Internet normally, you must
add a route on the uplink equipment; otherwise the
access to the Internet will fail. Normally, it is required
to enable NAPT.

PPP Settings

The correct user name that your ISP has provided to
you.

Password

The correct password that your ISP has provided to you

Connection Type

The choices are Continuous, Connect on Demand and
Manual.

Idle Time(min)

If select Connect on Demand, you need to input the
idle timeout time. Within the preset minutes, if the
MODEM doesn’t detect the flow of the user
continuously, the MODEM will automatically
disconnect the PPPOE connection.

WAN IP Settings

Type

The choices are Fixed IP and Use DHCP. If set Fixed IP,
you should enter the Local IP Address, Remote IP
Address and Subnet Mask. If set Use DHCP, your
MODEM will be a DHCP client, the WAN IP will be
assigned by the remote DHCP server.

Local IP Address

This is the IP of WAN interface which is provided by
your ISP.

Remote IP Address

This is the gateway IP which is provided by your ISP.

Subnet Mask

This is the Subnet Mask of the Local IP Address.

Unnumbered

Select this checkbox to enable IP Unnumbered
function.

Default Route

Add

After configuring the parameters of this page, click this
button then a new PVC will be added into Current ATM
