79
area
Language
Select a language from this dropdown menu to change display
language.
Display layout Change camera image display layout (Click a layout icon to
change camera display layout). There are 8 kinds of available
display layouts.
Full screen Click this button to switch to full screen mode (only display all
camera‟s image), press „ESC‟ key to quit full screen mode.
Scan
Click this button and the IP camera surveillance software will
switch displaying the image of all connected camera
automatically. Click this button once to activate scan function
(scan icon will become blue
), click again to stop scanning
(scan icon will become white ).
Zoom out Zoom-out (To see more objects).
This function is only available for supported cameras.
Zoom In Zoom-in (Too see more details).
This function is only available for supported cameras.
PTZ control
There are 8 directions in PTZ control ring. If the camera you
connect support PTZ, you can use PTZ control ring to change the
direction that camera points to.
This function is only available for supported cameras.
Home Click this button to return the camera to „Home‟ (default) position.
This function is only available for supported cameras.
Recording Start video recording.
Configure Software / camera configuration.
Playback Playback a recorded video file.
Snapshot Take a snapshot of current camera.
Message display Displays all system messages like camera is disconnected etc.
Close window
(stop surveillance) Terminates IP camera surveillance software.
Minimize window Minimizes IP camera surveillance software window.
