93
Item Name Description
Enable QoS Check this box to enable QoS function, uncheck it to
disable QoS.
Total Download
Bandwidth You can set the limit of total download bandwidth in
kbits. To disable download bandwidth limitation, input
‘0’ here.
Total Upload Bandwidth You can set the limit of total upload bandwidth in
kbits. To disable upload bandwidth limitation, input ‘0’
here.
Current QoS Table All existing QoS rules will be displayed here.
Add Click ‘add’ button to add a new QoS rule (detailed
instructions will be given below).
Edit If you want to modify the content of a specific rule,
please check the ‘select’ box of the rule you want to
edit, then click ‘Edit’ button. Only one rule should be
selected a time!
Delete You can delete selected rules by clicking this button.
You can select one or more rules to delete by check
the ‘select’ the box of the rule(s) you want to delete a
time. If the QoS table is empty, this button will be
grayed out and cannot be clicked.
Delete All By clicking this button, you can delete all rules
currently listed in the QoS table. If the QoS table is
empty, this button will be grayed out and cannot be
clicked.
Move Up Move selected rule up. First QoS rule will be proceed
first, so you can move higher priority rules up.
Move Down Move selected rule down.
After you finish with all settings, please click ‘Apply’ (11) button and the following message
will be displayed on your web browser:
