Edimax Technology BR-6428nS - Manual (Page 119)

118
Internet IP address will be mapped to.
Computer Name Pull down the menu and all the computers
connected to the router will be listed here.
You can easily to select the computer name
without checking the IP address of the
computer.
Port Range Input the starting port number in the left field,
and input the ending port number in the right
field. If you only want to redirect a single port
number, just fill the port number in the left
field.
Add Add the mapping to port forwarding table.
Reset Remove all inputted values.
Current DMZ Table All existing public IP address and private IP
address mapping will be displayed here.
Delete If you want to delete a specific DMZ entry,
check the ‘select’ box of the DMZ entry you
want to delete, then click ‘Delete Selected’
button. (You can select more than one DMZ
entries).
Delete All If you want to delete all DMZ entries listed
here, please click ‘Delete All’ button.
Reset You can also click ‘Reset’ button to unselect all
DMZ entries.
NOTE: Please note that every public IP address can be mapped to a single Client PC IP
address only.
All existing DMZ entries will be displayed in ‘Current DMZ Table’:
If you want to delete a specific DMZ entry, check the ‘select’ box of the DMZ entry you want
to delete, then click ‘Delete Selected’ button. (You can select more than one DMZ entries).
If you want to delete all DMZ entries listed here, please click ‘Delete All’ button or you can
also click ‘Reset’ button to unselect all DMZ entries.
When you finished with the settings in this page, you can click ‘Apply’ button to save
changes you made in this page, or you can click ‘Cancel’ to discard changes. After you click
‘Apply’ button, you’ll see the following messages:
