A-6
A
PPENDIX
A: C
ABLING
RJ-45 Connector Pin Assignments
Figure A-1 shows the RJ-45 connector pin assignments.
Figure A-1 RJ-45 Connector Pin Assignments
T4
T4
8
7
6
5
4
12 345678
3
2
1
BI_DI4–(8)
BI_DI4+(7)
RD–(6)
BI_DI3–(5)
BI_DI3+(4)
RD+(3)
TD–(2)
TD+(1)
