Multipliers for determining the performance with other indoor sections.
NOTE:
For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO.
E1RA060S(25,46
INDOOR COIL MODEL NO.
G2FD060(S,H)24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM
1600
1800
2000
ID DB (°F)
85
80
75
85
80
75
85
80
75
ID WB (°F)
71
67
63
71
67
63
71
67
63
65
T.C.
63.0
61.1
60.7
62.9
60.9
61.1
62.9
60.6
61.4
S.C.
39.6
39.7
40.3
41.6
41.5
42.2
43.7
43.3
44.1
KW
3.71
3.66
3.68
3.71
3.66
3.67
3.71
3.67
3.67
75
T.C.
62.3
59.8
57.9
62.5
60.0
58.5
62.6
60.1
59.0
S.C.
39.6
39.3
39.1
41.8
41.3
41.1
43.9
43.3
43.1
KW
4.20
4.14
4.12
4.21
4.15
4.13
4.21
4.16
4.13
85
T.C.
61.7
58.5
55.1
62.0
59.1
55.9
62.3
59.6
56.6
S.C.
39.6
38.9
38.0
41.9
41.1
40.1
44.2
43.3
42.2
KW
4.70
4.63
4.57
4.71
4.64
4.58
4.72
4.65
4.60
95
T.C.
61.0
57.2
52.3
61.5
58.2
53.3
62.0
59.1
54.2
S.C.
39.6
38.5
36.8
42.0
40.9
39.0
44.4
43.3
41.2
KW
5.19
5.11
5.01
5.21
5.13
5.04
5.22
5.14
5.06
105
T.C.
58.3
53.9
49.1
59.1
54.7
49.9
60.0
55.6
50.7
S.C.
38.5
37.2
35.4
41.0
39.6
37.6
43.6
41.9
39.8
KW
5.78
5.67
5.55
5.80
5.69
5.57
5.82
5.71
5.60
115
T.C.
55.5
50.5
45.9
56.8
51.3
46.5
58.0
52.1
47.1
S.C.
37.4
35.9
34.0
40.1
38.2
36.2
42.7
40.5
38.3
KW
6.36
6.22
6.08
6.39
6.25
6.11
6.41
6.27
6.13
NOTE:
ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler
Coil
T.C.
S.C.
KW
MA20DN2,4
FC/MC60D3X
1.00
1.00
1.00
N1AHD2046
G2FD060(S,H)24
1.00
1.00
1.00
AHP/SHP60D3X
–
0.98
0.98
1.02
F2FP060
–
0.98
0.98
1.02
–
G1FA060S21,24
1.00
1.00
1.00
–
G1UA060S21,24
1.00
1.00
1.00
–
FC/MC/PC/UC60*3X
1.00
1.00
1.00
