123
MIDI PARAMETER CHANGE TABLE
MIDI Parameter Change table (XG SYSTEM)
TOTAL SIZE 07
MIDI Parameter Change table (SYSTEM INFORMATION)
TOTAL SIZE 10
MIDI Parameter Change table (EFFECT1)
TOTAL SIZE 0E
TOTAL SIZE 06
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
PLAY REC
Song
Main
Layer
Left
Left-layer
Keyboard
Panel
Song MIDI PLAY REW
Panel
00 00 00
01
02
03 4 00-0F
00-0F
00-0F
00-0F MASTER TUNE -102.4...0...+102.3[cent]
1st bit3-0
→ bit15-12
2nd bit3-0 → bit11-8
3rd bit3-0 → bit7-4
4th bit3-0 → bit3-0
*Panel Ш ˛ Ш ˛ Ш ˛ ˛
04 1 00-7F MASTER VOLUME 0...127 7F Ш ˛ ˛ ˛ Ш ˛ Ш Ш ˛
05 1 00-7F MASTER ATTENUATOR 0...127 00 ˛ ˛ ˛ ˛ ˛ ˛ ˛ ˛ ˛
06 1 28-58 TRANSPOSE -24...0...+24[semitones] 40 Ш ˛ ˛ ˛ Ш ˛ Ш Ш ˛
7D 1 N DRUM SETUP RESET N: Drum setup number – Ш ˛ ˛ ˛ Ш ˛ Ш ˛ ˛
7E 1 00 XG SYSTEM ON 00=XG system ON – Ш ˛ ˛ ˛ Ш ˛ Ш ˛ ˛
7F 1 00 ALL PARAMETER RESET 00=ON – Ш ˛ ˛ ˛ Ш ˛ Ш ˛ ˛
Address
(H)
Size
(H)
Data
(H)
Parameter Description
PLAY REC
Song
Main
Layer
Left
Left-layer
Keyboard
Panel
Song MIDI PLAY REW
Panel
01 00 00
...
0D
E 20-7F
...
20-7F
Model Name 1
...
Model Name 14 32...127 (ASCII CHARACTER)
...
32...127 (ASCII CHARACTER)
– – – ˛ ˛ Ø ˛ ˛ ˛
0E 1 NOT USED
0F 1 NOT USED
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
PLAY REC
Song
Main
Layer
Left
Left-layer
Keyboard
Panel
Song MIDI PLAY REW
Panel
02 01 00 2 00-7F REVERB TYPE MSB
REVERB TYPE LSB 01(=HALL1)
00 Ш Ш
(Voice Setting)
Ш ˛ Ш Ш ˛
02 1 00-7F REVERB PARAMETER 1 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
03 1 00-7F REVERB PARAMETER 2 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
04 1 00-7F REVERB PARAMETER 3 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
05 1 00-7F REVERB PARAMETER 4 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
06 1 00-7F REVERB PARAMETER 5 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
07 1 00-7F REVERB PARAMETER 6 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
08 1 00-7F REVERB PARAMETER 7 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
09 1 00-7F REVERB PARAMETER 8 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
0A 1 00-7F REVERB PARAMETER 9 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
0B 1 00-7F REVERB PARAMETER 10 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
0C 1 00-7F REVERB RETURN - ∞ dB...0dB...+6dB (0...64...127) 40 Ш ˛ Ш ˛ Ш Ш ˛
0D 1 01-7F REVERB PAN L63...C...R63 40 Ш ˛ Ш ˛ Ш Ш ˛
02 01 10 1 00-7F REVERB PARAMETER 11 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
11 1 00-7F REVERB PARAMETER 12 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
12 1 00-7F REVERB PARAMETER 13 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
13 1 00-7F REVERB PARAMETER 14 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
14 1 00-7F REVERB PARAMETER 15 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
15 1 00-7F REVERB PARAMETER 16 Reverb Type Ø
(Reverb Type )
˛ Ш ˛ Ш Ш ˛
Address
(H)
Size
(H)
Data
(H)
Parameter Description
XG Default
(H)
PLAY REC
Song
Main
Layer
Left
Left-layer
Keyboard
Panel
Song MIDI PLAY REW
Panel
02 01 20 2 00-7F CHORUS TYPE MSB
CHORUS TYPE LSB 01 (=CHORUS1)
00
Ш Ш
(Voice Setting)
Ш ˛ Ш Ш Ш
22 1 00-7F CHORUS PARAMETER 1 Chorus Type Ø
(Chorus Type )
˛ Ш ˛ Ш Ш ˛
23 1 00-7F CHORUS PARAMETER 2 Chorus Type Ø
(Chorus Type )
˛ Ш ˛ Ш Ш ˛
