109
MSB = 09
MSB = 10
MSB = 11
MSB = 16
MSB = 17
MSB = 18
MSB = 19
MSB = 20
MSB = 21
MSB = 22
Insertion block
Rotary
Chorus Block
Chorus MSB = 65
Celeste LSB = 66
Chorus block
Flanger MSB = 67
No. Parameter Display Value See Table Control
1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0 – 5
2 Room Size 0.1 – 20.0 0 – 127 table#6
3 Diffusion 0 – 10 0 – 10
4 Initial Delay 0.1mS – 200.0mS 0 – 127 table#5
5 Feedback Level -63 – +63 1 – 127 (table#16)
6 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
7 LPF Cutoff 1.0kHz – Thru 34 – 60 table#3
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 Liveness 0 – 10 0 – 10
12 Density 0 – 3 0 – 3
13 High Damp 0.1 – 1.0 1 – 10
14
15
16
No. Parameter Display Value See Table Control
1 Type TypeA, TypeB 0 – 1
2 Room Size 0.1 – 20.0 0 – 127 table#6
3 Diffusion 0 – 10 0 – 10
4 Initial Delay 0.1mS – 200.0mS 0 – 127 table#5
5 Feedback Level -63 – +63 1 – 127 (table#16)
6 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
7 LPF Cutoff 1.0kHz – Thru 34 – 60 table#3
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 Liveness 0 – 10 0 – 10
12 Density 0 – 3 0 – 3
13 High Damp 0.1 – 1.0 1 – 10
14
15
16
No. Parameter Display Value See Table Control
1 Reverb Time 0.3 – 30.0s 0 – 69 table#4
2 Diffusion 0 – 10 0 – 10
3 Initial Delay 0.1mS – 200.0mS (*1) 0 – 127 table#5
0.1mS – 99.3mS (*2) 0 – 63
4 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
5 LPF Cutoff 1.0kHz – Thru 34 – 60 table#3
6 Width 0.5 – 30.2m (*1) 0 – 104 table#11
0.5 – 10.2m (*2) 0 – 37
7 Height 0.5 – 30.2m (*1) 0 – 104 table#11
0.5 – 20.2m (*2) 0 – 73
8 Depth 0.5 – 30.2m 0 – 104 table#11
9 Wall Vary 0 – 30 0 – 30
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 Rev Delay 0.1mS – 200.0mS (*1) 0 – 127 table#5
0.1mS – 99.3mS (*2) 0 – 63
12 Density 0 – 4 0 – 4
13 Er/Rev Balance E63>R – E=R – E 1 – 127
14 High Damp 0.1 – 1.0 1 – 10
15 Feedback Level -63 – +63 1 – 127 (table#16)
16
No. Parameter Display Value See Table Control
1 Delay Time 0.1mS – 400.0mS 0 – 127 table#7
2 Feedback Level -63 – +63 1 – 127 (table#16)
3 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
4 LPF Cutoff 1.0kHz – Thru 34 – 60 table#3
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 Density 0 – 3 0 – 3
12
13
14
15
16
No. Parameter Display Value See Table Control
1 Delay Time 64th/3 – 4thx6 0 – 19 table#14
2 Feedback Level -63 – +63 1 – 127 (table#16)
3 Feedback High Dump 0.1 – 1.0 1 – 10
4 L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
5 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 Delay Time L>R 64th/3 – 4thx6 0 – 19 table#14
2 Delay Time R>L 64th/3 – 4thx6 0 – 19 table#14
3 Feedback Level -63 – +63 1 – 127 (table#16)
4 Input Select L, R, L&R 0 – 2
5 Feedback High Dump 0.1 – 1.0 1 – 10
6 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2 LFO Depth 0 – 127 0 – 127 (table#19)
3 Feedback Level -63 – +63 1 – 127 (table#17)
4 Delay Offset 0.0mS – 50mS 0 – 127 table#2
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 0.1 – 12.0 1 – 120
14
15 Input Mode mono/stereo 0 – 1
16
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2 LFO Depth 0 – 127 0 – 127 (table#19)
3 Feedback Level -63 – +63 1 – 127 (table#17)
4 Delay Offset 0.0mS – 50mS 0 – 127 table#2
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 EQ Mid Frequency
(*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 0.1 – 12.0 1 – 120
14 LFO Phase Difference -180 – +180deg
(resolution=3deg.) 4 – 124
15
16
