113
MSB = 82, LSB = 8, 18, 19
MSB = 82, LSB = 2, 17
MSB = 83
MSB = 84
MSB = 85
MSB = 86, LSB = 0
MSB = 86, LSB = 1
MSB = 86, LSB = 2
MSB = 86, LSB = 3
No. Parameter Display Value See Table Control
1 Sensitivity 0 – 127 0 – 127
2 Cutoff Frequency Offset 0 – 127 0 – 127 ●
3 Resonance 1.0 – 12.0 10 – 120
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15)
11 Drive (*4) 0 – 127 0 – 127
12 EQ Low Gain (*4)
(distortion) -12 – +12dB 52 – 76
13 EQ Mid Gain (*4)
(distortion) -12 – +12dB 52 – 76
14 LPF Cutoff (*4) 1.0kHz – thru 34 – 60 table#3
15 Output Level (*4) 0 – 127 0 – 127 (table#18)
16 Release 10 – 680mS 52 – 67 table#12
No. Parameter Display Value See Table Control
1 Sensitivity 0 – 127 0 – 127
2 Cutoff Frequency Offset 0 – 127 0 – 127 ●
3 Resonance 1.0 – 12.0 10 – 120
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15)
11 Drive 0 – 127 0 – 127
12 EQ Low Gain (distortion) -12 – +12dB 52 – 76
13 EQ Mid Gain (distortion) -12 – +12dB 52 – 76
14 LPF Cutoff 1.0kHz – thru 34 – 60 table#3
15 Output Level 0 – 127 0 – 127 (table#18)
16 Release 10 – 680mS 52 – 67 table#12
No. Parameter Display Value See Table Control
1 Attack 1 – 40ms 0 – 19 table#8
2 Release 10 – 680ms 0 – 15 table#9
3 Threshold -48 – -6dB 79-121
4 Ratio 1.0 – 20.0 0 – 7 table#10
5 Output Level 0 – 127 0 – 127 (table#18)
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1 Attack 1 – 40ms 0 – 19 table#8
2 Release 10 – 680ms 0 – 15 table#9
3 Threshold -72 – -30dB 55 – 97
4 Output Level 0 – 127 0 – 127 (table#18)
5
6
7
8
9
10
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1
2
3
4
5
6
7
8
9
10
11 Low Adjust 0 – 26 0 – 26
12 High Adjust 0 – 26 0 – 26
13
14
15
16
No. Parameter Display Value See Table Control
1 Rotor Speed 0.0Hz – 39.7Hz 0 – 127 table#1 ●
2 Drive Low 0 – 127 0 – 127
3 Drive High 0 – 127 0 – 127
4 Low/High L63>H – L=H – L 1 – 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 – 54 table#3
12 Mic L-R Angle 0deg – 180deg
(resolution=3deg.) 0 – 60
13
14
15
16
No. Parameter Display Value See Table Control
1 Rotor Speed 0.0 – 39.7Hz 0 – 127 table#1 ●
2 Drive Low 0 – 127 0 – 127
3 Drive High 0 – 127 0 – 127
4 Low/High Balance L63>H – L=H – L 1 – 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 – 54 table#3
12 Mic L-R Angle 0 – 180deg 0 – 60
13
14 Drive 0 – 127 0 – 127
15 LPF Cutoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127 0 – 127 (table#18)
No. Parameter Display Value See Table Control
1 Rotor Speed 0.0 – 39.7Hz 0 – 127 table#1 ●
2 Drive Low 0 – 127 0 – 127
3 Drive High 0 – 127 0 – 127
4 Low/High Balance L63>H – L=H – L 1 – 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 – 54 table#3
12 Mic L-R Angle 0 – 180deg 0 – 60
13 AMP Type Off, Stack, Combo, Tube 0 – 3
14 Drive 0 – 127 0 – 127
15 LPF Cutoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127 0 – 127 (table#18)
