York YZE024 THRU 060 - Manual (Page 12)

12 Johnson Controls Unitary Products
246750-YTG-L-0408
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTE: KW RATING IS FOR OUTDOOR AND INDOOR UNITS.
LOW CFM
COOLING PERFORMANCE DATA - LOW CFM 1-STAGE OPERATION
OUTDOOR UNIT MODEL NO. YZE02411
INDOOR COIL MODEL NO. FC/MC36B + MV12B
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 550 600 650
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 57 62 62 67 72 57
65
T.C. 19.5 30.3 25.6 25.2 19.8 20.4 31.2 26.6 26.2 20.0 21.4 32.2 27.6 27.1 20.3
S.C. 18.0 3.2 3.2 3.3 3.3 18.8 3.3 3.2 3.3 3.3 19.7 3.3 3.2 3.3 3.3
K.W. 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.1 1.1 1.1 1.0 1.0
75
T.C. 18.6 19.2 18.4 20.8 22.6 19.5 19.7 18.8 21.2 23.2 20.3 20.3 19.2 21.5 23.7
S.C. 17.1 16.7 13.7 14.1 11.1 17.9 17.7 14.5 14.8 11.7 18.6 18.6 15.2 15.5 12.4
K.W. 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.1 1.1 1.2 1.2 1.2 1.1 1.1
85
T.C. 17.7 18.1 17.4 19.6 21.3 18.5 18.5 17.9 19.9 21.6 19.3 19.0 18.4 20.2 22.0
S.C. 16.2 16.0 13.2 13.6 10.7 16.9 16.9 13.9 14.1 11.3 17.6 17.8 14.6 14.7 11.8
K.W. 1.4 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.2 1.2
95
T.C. 16.9 17.0 16.4 18.3 20.0 17.6 17.4 16.7 18.6 20.3 18.4 17.9 17.1 18.9 20.5
S.C. 15.3 15.3 12.6 13.0 10.3 16.0 16.1 13.3 13.6 10.8 16.7 17.0 14.0 14.2 11.3
K.W. 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
105
T.C. 16.1 16.0 15.2 17.1 18.6 16.8 16.4 15.5 17.4 18.8 17.5 16.8 15.9 17.6 19.0
S.C. 14.6 14.8 12.1 12.5 9.9 15.2 15.5 12.7 13.1 10.3 15.8 16.2 13.4 13.7 10.7
K.W. 1.8 1.7 1.8 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7
115
T.C. 15.4 15.0 14.0 15.9 17.2 16.0 15.3 14.3 16.1 17.4 16.7 15.7 14.7 16.4 17.6
S.C. 13.8 14.3 11.6 12.1 9.4 14.4 14.8 12.2 12.6 9.8 14.9 15.4 12.8 13.2 10.2
K.W. 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.9 2.0 2.0 2.0 2.0 1.9
125
T.C. 14.7 13.9 12.8 14.7 15.8 15.3 14.3 13.1 14.9 16.0 15.8 14.6 13.4 15.1 16.2
S.C. 13.1 13.7 11.0 11.6 9.0 13.6 14.2 11.6 12.2 9.4 14.1 14.6 12.2 12.7 9.7
K.W. 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
AV24 – 1.01 1.00 1.00
AV36 – 1.01 1.00 1.00
MV12B FC/MC30B 0.97 1.06 1.00
MV12B FC/MC35B 0.97 1.06 1.00
MV12B FC/MC36B 1.00 1.00 1.00
MV12B FC/MC42B 0.97 1.06 1.00
MV16C FC/MC35C 1.00 1.00 1.00
MV16C FC/MC42C 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
PV8*A12 FC/MC/PC30A 0.99 1.06 1.01
PV9*A12 FC/MC/PC30A 0.99 1.06 1.01
P(C,V)9*B12 FC/MC/PC30B 0.99 1.06 1.01
PV9*A12 FC/MC/PC32A 0.99 1.06 1.01
P(C,V)9*B12 FC/MC/PC35B 0.99 1.06 1.01
PV8*A12 FC/MC/PC36A 0.94 0.85 0.92
PV9*A12 FC/MC/PC36A 0.99 1.01 0.99
P(C,V)9*B12 FC/MC/PC36B 0.99 1.01 0.99
P(C,V)9*B12 FC/MC/PC42B 0.96 0.99 0.98
P(C,V)9*B12 HC30 0.96 0.99 0.98
P(C,V)9*B12 HC36 0.99 1.01 0.99
P(C,V)9*B12 HD36 0.99 1.01 0.99
PV8*A12 UC30A 0.96 0.99 0.98
P(C,V)9*B12 UC30B 0.96 0.99 0.98
PV8*A12 UC36A 0.99 1.01 0.99
P(C,V)9*B12 UC36B 0.99 1.01 0.99
P(C,V)9*B12 UC42B 0.99 1.01 0.99
